Top Dresser - ECO50

Technical specification
| Gate |
On⁄off gate system
|
|
Included
|
Four tie-down points
|
|
Conveyor belt
|
Cresent top
|
|
Application Speed
|
9 ft3/min – 540 ft3/h
(0.26M³/min – 15.29 M³/h)
|
|
Application Width
|
3 to 12 ft (0.91 to 3.66 m)
|
|
Application Thickness
|
Up to 1/4 in. (6.35 mm)
|
|
Materials
|
Light soil mix, Screened compost, Rubber Crumb
|
| Hopper Capacity
|
11.5 ft3 (326 L)
|
| Broadcasting Drive & Mechanism
|
Belt-driven system with single disk / spinner
|
| Ground speed
|
Up to 5 mph (8 km/h)
|
| Weight Distribution Design
|
Two-wheel design
|
|
Empty Weight
|
242 lbs (110 kg)
|
|
Dimension (L/W/H)
|
78 x 34 x 40 in.
(1981 × 864 × 1016 mm)
|
|
Warranty
|
One (1) year commercial use on parts and labor
|
|
Certification
|
CE Certified
|
|
